Product features
Reasonable structure
Stable performance
Easy maintenance
Energy-efficiency
Vapor Generator
Product details
The vapor generator includes throttle valve、constant-flux pump、electric heater and so on, and can output small flow saturated vapor and superheated steam. The pressure、flow、dryness can be adjusted accurately.
Accuracy: flow: ±0.1%, pressure: ±0.25%, temperature: ±1.5℃
I-type parameters:
Flow range: 2ml/min-50ml/min
Working pressure: 0MPa-22MPa
Working temperature: 0℃-374℃
Heating medium: distilled water
Boiler consumption: 3kW
Dryness of steam: 0-100%, controlled
II-type parameters:
Flow range: 2ml/min-250ml/min
Working pressure: 0MPa-4MPa
Working temperature: 0℃-374℃
Heating medium: distilled water
Boiler consumption: 14kW
Dryness of steam: 0-100%, controlled
Linear steam thermal production simulation device
The device will simulate the filling steam to oil product oil well and research the steam thermal production technology.
The vapor generator will produce the saturated vapor and superheated steam.
The pressure、flow、dryness can be adjusted accurately.
